Available Laminates
- Fr-4
- High Tg Fr-4
- Halogen Free Fr-4
- BT Resin
- Polyimide
- Teflon
- Rogers Material
Specifiction
| Item | Unit | Standard | Special | Remarks |
|---|---|---|---|---|
| Total Thickness | ㎜ | 0.4 ~ 1.8 | 0.1 ~ 0.39, 1.81 ~ 6.4 | - |
| Base Copper Thickness | ㎛ | 17, 35 | 8, 12, 70, 105 | - |
| Line Width/Space | ㎛ | 125 ~ | 75 ~ 125 | - |
| Minimum Hole Size | ㎜ | 0.3 | 0.1 ~ 0.25 | - |
| Surface Treatment | - | OSP. HOT AIR SOLDER LOVELLING(PB-FREE) | FLASH GOLD IMMERSION TIN CARBON PASTE, PEELABLE COATING | - |
